Mila Ideal Flag Hinge 100mm- White

Product description

Mila Ideal Flag Hinge 100mm- White

Features

3 dimensional adjustment
Vertical (+4mm)
Lateral (+/- 5mm)
Compression (+/- 1mm) for fine tuning

Adjustment with 5mm Allen key achieved without removing door leaf from frame
Steel hinge pin for enhanced strength
Captive sash retaining screw for simple sash lid fitting
“Lift-on, lift-off” design for efficient on-site installation by one person
Positive location of the top cover cap and height adjustment packer further eases fabrication
4 over-rebate bushes to fit over-rebate heights 14-24mm
Utilises only 1 frame packer to alter over-rebate heights by a further 4mm, suiting a range of profile systems
“Friction fit” packer for ease of fabrication

Application uses

Hinge to suit rebate heights 14 – 25mm
Suits doors up to 80Kg (2 Hinges)
